Cicada Audio CMB10.S4 - 10-Inch Pro Mid-Bass, Sold Individually





Product details

600W RMS / 1200 MAX Power Handling - SOLD INDIVIDUALLY
• 4 Ohm Single Voice Coil
• Ferrite Magnet Structure
• Heavy Duty / High Temp Cast Aluminum Basket
• 3.0” High Temp 6 Layer (BlackCoat ) Voice Coil
• Vented Voice Coil Gap for Maximum Heat disipation
• Water Resistant Treated Cone with NBR Surround
• Frequency Response: 35Hz -1.75Khz +/- 5dB
• Sensitivity: 83.5dB (1W/1M)

Component High Performance Mid-Bass Driver
Size mm (in.): 10 (260)
Power Handling WRMS/Peak: 600 WRMS/1200W Hi-pass@ 45Hz-12 dB Oct.
Impedance: 4 Ohm - Single Voice Coil
Frequency Response Hz: 30Hz -1.75k +/- 5dB
Sensitivity dB/SPL: 87.2dB (1W/1M)
Voice Coil Ø in. (mm): 3.0 (76.2)
Voice Coil Former: Aluminium
Voice Coil Layers: 6- Layer Coil
Magnet: Ferrite
Frame: Cast Aluminium
Weight lb. (kg): 18.7 (8.5)

ELECTRO-ACOUSTIC PARAMETERS
D, inches / mm: 10 / 260
Re, Ω: 4
Fs, Hz: 41.1
Le, mH: @ 1 kHz 0.94
Vas, I: 18.3
Mms, g: 144
Cms, mm/N: 0.10
BL, T•: m 18.1
Qts: 0.33
Qes: 0.37
Qms: 3.17
Spl, dB: 87.2dB (1W/1M)
